Model:
|
Stimular 12A
|
Stimular 10A
|
|
|
|
|
LF Unit:
|
12" x2(neodymium)
|
10" x2(neodymium)
|
|||
|
MF Unit:
|
6.5" x4(neodymium)
|
||||
|
HF Unit:
|
3"x2(neodymium)
|
3"x1(neodymium)
|
|||
|
Cabinet and paiting:
|
Birch of plywood and Polyurea
|
Birch of plywood and Polyurea
|
|||
|
Frequency Response:
|
60Hz-18KHz(±3dB)
|
80Hz-18KHz(±3dB)
|
|||
|
Nominal Impedance:
|
LF:4ohms/MF:4ohms/HF:4ohms
|
LF:4ohms/HF:8ohms
|
|||
|
Input Sensitivity:
|
101dB LF,106dB MF,112dB HF(1W/1m)
|
100dB LF,112dB HF(1W/1m)
|
|||
|
AES Power :
|
2000W LF,1200W MF,600W HF
|
1400W LF,220W HF
|
|||
|
Peak Power:
|
4000W LF,2400W MF,1200W HF
|
2800W LF,440W HF
|
|||
|
Max SPL:
|
128dB LF,132dB MF,135dB HF
|
132dB LF,138dB HF
|
|||
|
Input Connector:
|
1xXLR female+1xXLR male
1xVolume,1xpreset,USB,Dante
|
1xXLR female+1xXLR male
1xVolume,1xpreset,USB,Dante
|
|||
|
Amplifier @THD1%RMS:
|
2500Wx800Wx800W@4ohm
|
2500Wx800W@4ohm
|
|||
|
DSP:
|
96KHz sample rate,
floating point DSP
Phase,All past filter,12 EQ,
Crossover,Limiter
1000ms for each input and output
Driver free
APP for IOS/Androi(new version)
|
96KHz sample rate,
floating point DSP
Phase,All past filter,12 EQ,
Crossover,Limiter
1000ms for each input and output
Driver free
APP for IOS/Androi(new version)
|
|||
|
Dante:
|
selectable
|
selectable
|
|||
|
WIFI:
|
Ethernet by TCP/IP
|
Ethernet by TCP/IP
|
|||
|
Standby and Green energy:
|
Yes(<0.8W)
|
Yes(<0.8W)
|
|||
|
Working Voltage:
|
85-265V,with PFC
|
85-265V,with PFC
|
|||
|
Dimensions(WxDxH):
|
1115x505x375mm
|
900x407x285mm
|
|||
|
Weight:
|
68.5kg
|
42kg
|
|
|
|
